Functions of automatic soldering machine

Automatic soldering machine 3-degree space adjustment,Automatic soldering machineThe soldering iron\/UL soldering station, solder nozzle and tin wire do not need to be passed through the hands of the operator. The automatic soldering machine completely replaces your hands. The automatic soldering machine arm can be adjusted to any soldering position you want. Automatic tin delivery System: You only need to lightly press the foot switch, and the tin wire will automatically reach the soldering iron head temperature at a fixed speed and quantitatively: Use manual digital temperature setting to be clear at a glance, and automatic constant temperature control method.

Highly reliable metal anti-static mode design, welding sensitive components are safer. Lightweight and flexible, does not occupy space, temperature, tin delivery speed, and adjustable tin point size. Easy to control for 2 hours, novices can be proficient in 2 hours, saving 50% of manpower. For health, please Use environmentally friendly lead-free tin wires. They are especially suitable for welding and docking between various electronic connectors, LED light strings, video and audio cable plugs, headphone cables, computer data cables, small circuit boards and small electronic components wiring harnesses.

Equipment Features

1. The TM soldering iron head with fast temperature recovery can be installed in the entire series of machines for the future trend of "lead-free soldering". High-precision thermoelectric coupling is located at the front end of the soldering iron. Therefore, the slight changes in the front end of the soldering iron head can be sensed. .

· It can reach 300 degrees C in 6 seconds.

· The card-designed soldering iron tip is quick to replace and is easy to use.

· The soldering iron has a variety of forms and can quickly solve the difficult soldering process.

2. The tin-burst-proof tin sender ZSB (Geyan) can be installed in the entire series of machine models

While sending tin in precision, the knife-shaped gear protrudes on the side of the tin wire to prevent flux from oozing out, so that the flux will not boil during the soldering process

The "tin burst" will ensure the cleanliness of the soldering site, and there will be no flux or the hot balls generated by the tin burst that will affect other PCB boards.

Sensitive components.

3. RSP\/RSL soldering iron set with auxiliary tin delivery function

RSP and RSL are designed for automatic soldering.

The feed position of the soldering iron tip can be adjusted twice by adjusting the up and down positioning parts. The first section of the soldering iron can be used to send the soldering iron head or solder.

The pre-tightening of the joints can make the welding results faster and perfect.

4. A card soldering iron set that can directly blow nitrogen gas

Integrate the nitrogen nozzle and the soldering iron head into one, and the preheated nitrogen can be blown out from the tip of the soldering iron head, and a small amount of nitrogen can meet the process requirements.

Current development status

Solder robot, as the name suggests, is a solder soldering equipment. Therefore, in addition to the movement function of the robot, it mainly needs to complete soldering operations. Therefore, the core part of the solder robot is the welding system. The solder system is mainly composed of automatic tin delivery mechanism and temperature control, and heating. At present, some domestic brands of soldering robots in the domestic market have been successfully used in automotive electronics, digital, electronics, electroacoustics, LCD, circuit board and other production industries.
